UV Spotlights

UV Spotlights

OVERVIEW

UV Spotlights are lighting devices that use ultraviolet light sources, mainly for specific applications. They use ultraviolet light, which is usually divided into three bands: UVA, UVB and UVC. The parameters of UV Spotlights include power, wavelength range, coverage area and service life, etc.

PRODUCT

Model

Description

Order Code

Material

Product Size (mm)

LED

Voltage

Power/w

Initial Lumens/LM

Color

Effect  LM/W

IP

Deg

Part No.

50W UVA Flood Light

QD-FLUVA-50W

QDFLUV301

aluminum + glass

167.0mm*199.5mm*40.0mm

2835

AC165-265V

50W±5%

PF>0.9

395

100LM/W

IP65

120°

9405500000UV01

100W UVA  Flood Light

QD-FLUVA-100W

QDFLUV302

aluminum + glass

219.5mm*265.0mm*50.5mm

2835

AC165-265V

100W±5%

PF>0.9

395

100LM/W

IP65

120°

9405500000UV02

150W UVA  Flood Light

QD-FLUVA-150W

QDFLUV303

aluminum + glass

244.5mm*298.5mm*55.0mm

2835

AC165-265V

150W±5%

PF>0.9

395

130LM/W

IP65

120°

9405500000UV03

200W UVA  Flood Light

QD-FLUVA-200W

QDFLUV304

aluminum + glass

295.0mm*244.5mm*60.0mm

2835

AC165-265V

200W±5%

PF>0.9

395

130LM/W

IP65

120°

9405500000UV04

300W UVA  Flood Light

QD-FLUVA-200W

QDFLUV305

aluminum + glass

360.0mm*400.0mm*60.0mm

2835

AC165-265V

300W±5%

PF>0.9

395

130LM/W

IP65

120°

9405500000UV05

50W UVB Flood  Light

QD-FLUVB-50W

QDFLUV306

aluminum + glass

167.0mm*199.5mm*40.0mm

2835

AC165-265V

50W±5%

PF>0.9

365

100LM/W

IP65

120°

9405500000UV06

100W UVB  Flood Light

QD-FLUVB-100W

QDFLUV307

aluminum + glass

219.5mm*265.0mm*50.5mm

2835

AC165-265V

100W±5%

PF>0.9

365

100LM/W

IP65

120°

9405500000UV07

150W UVB  Flood Light

QD-FLUVB-150W

QDFLUV308

aluminum + glass

244.5mm*298.5mm*55.0mm

2835

AC165-265V

150W±5%

PF>0.9

365

130LM/W

IP65

120°

9405500000UV08

200W UVB  Flood Light

QD-FLUVB-200W

QDFLUV309

aluminum + glass

295.0mm*244.5mm*60.0mm

2835

AC165-265V

200W±5%

PF>0.9

365

130LM/W

IP65

120°

9405500000UV09

300W UVB  Flood Light

QD-FLUVB-300W

QDFLUV310

aluminum + glass

360.0mm*400.0mm*60.0mm

2835

AC165-265V

300W±5%

PF>0.9

365

130LM/W

IP65

120°

9405500000UV10

FEATURES

UV Spotlights use ultraviolet wavelengths, usually between 200 and 400nm.

It emits a high-intensity UV beam with adjustable light intensity.

UV Spotlights usually use LEDs as the light source, so they have the characteristics of long life and low energy consumption.It starts up and shuts down quickly with no warm-up time.

UV Spotlights usually have a compact design, easy to carry and install.

Specifications

The wavelength range of UV Spotlights is also an important parameter.

The wavelength range of UVA band is between 315nm and 400nm,

The wavelength range of UVB band is between 280nm and 315nm,

The wavelength range of the UVC band is between 100 nanometers and 280 nanometers.

Different wavelength bands of ultraviolet light sources have different applications, so it is very important to choose the appropriate wavelength band according to the needs.

Its light intensity is usually between 1000 and 10000 mW/cm2.

UV Spotlights typically range from 10 to 300 watts.

BENEFITS

UV Spotlights have a wide range of applications in certain fields, such as medical, scientific research, industry, etc.

They can be used in applications such as UV curing, UV sterilization, UV inspection, and more.

UV Spotlights have high-efficiency UV exposure and can complete the task in a short time.

Compared with traditional lighting equipment, UV Spotlights have a longer life and lower energy consumption.

They are usually waterproof and dustproof.

APPLICATION

Medical industry: UV Spotlights can be used for irradiation therapy, such as photosensitizer therapy, skin disease treatment, etc.

Scientific research: UV Spotlights can be used in laboratory research, such as DNA analysis, fluorescence detection, etc.

Industrial application: UV Spotlights can be used for UV curing, such as ink curing, coating curing, etc.

Security detection: UV Spotlights can be used to detect counterfeit banknotes, ID cards, fluorescent dyes, etc.



In conclusion, UV Spotlights are high-efficiency, long-life UV lighting devices with a wide range of applications. They play an important role in medicine, scientific research and industry, and can also be used in fields such as safety detection.
