Filter

T10 LED Grow Tubes

Technical Specifications

Dimensions: Ø32 mm × 600/900/1200/1500 mm (standard T10 lengths)
Light Source: High-efficiency SMD LEDs
Housing: Optical-grade polycarbonate (PC) tube with aluminum end caps for heat dissipation
Color Temperature: 3000K / 6000K
Spectral Range: 380–730 nm full spectrum
Spectral Options:
Full-Spectrum White: Blend of 3000K (warm) and 6000K (cool) white LEDs, CRI >90, suitable for full-cycle growth.
Targeted RB Blend: 60% Deep Red (660nm) + 40% Blue (450nm) for propagation and compact morphology.
Custom spectral ratios available upon request.
Power Options: 60W, 80W, 100W (model dependent; high-output T10 series)
Input Voltage: AC 85–265V, 50/60Hz (universal auto-ranging)
Power Factor: ≥0.90
Photon Efficacy (PPE): 2.7–2.9 μmol/J (@25°C)
PPF Output: 162 µmol/s (60W), 216 µmol/s (80W), 270 µmol/s (100W)
Beam Angle: 120° typical (FWHM) for uniform canopy coverage
Operating Ambient Temperature: −25°C to +40°C
Protection Rating: IP65 (dust-tight and protected against water jets)
Lifespan: >50,000 hours (L90/B50 at 25°C)
LED Chip Brands: Philips, OSRAM, Samsung, Hongli
Driver Brands: Internal constant-current driver (Moso / Inventec / self-developed)
Installation: PG7 (M16) waterproof cable gland; mounted using side or top brackets (included). Direct replacement for fluorescent tubes is not supported – requires hardwired line-voltage connection.
Certifications: UL 8800, EN 62471, RoHS, CE
Note: Not compatible with existing fluorescent ballasts or electronic starters. Wiring must be line-voltage direct. High-power models (≥60W) require adequate ventilation.

Description

T10 LED Grow Tubes

Overview

The T10 LED grow tube features an integrated, one-piece design that eliminates complex assembly and enables tool-free, rapid installation. Engineered for small to mid-scale horticultural applications—including indoor gardening, greenhouses, and research labs—the T10 delivers targeted red-blue (RB) or full-spectrum white (WW) lighting with high photosynthetic efficiency. With PPF up to 174 µmol/s and efficacy of 2.9 µmol/J, it offers exceptional energy savings without compromising plant performance.

Product Electrical Index

Electrical & Photometric Specifications
Metric / Model	2FT	3FT	4FT	5FT	6FT
Input Voltage & Frequency	AC 85–230 V, 50/60 Hz
Rated Power (Typical W)	20	36	48	60	100
Power Factor (PF)	≥ 0.95	≥ 0.95	≥ 0.95	≥ 0.95	≥ 0.95
Dimming	Optional 0-10V, PWM
Driver Lifetime	~ 50 000h (L90>36 000h at 25°C)
Photometric Performance
WAVELENGTH [1] (nm)	370-730 nm	370-730 nm	370-730 nm	370-730 nm	370-730 nm
Photosynthetic Photon Flux (PPF) (µmol/s)	54	97	130	162	270
System Efficacy (PPE) (μmol/J)	2.7	2.7	2.7	2.7	2.7
LED-Only Efficacy (µmol/J)	3.02	3.02	3.02	3.02	3.02
Spectral Half-width (nm) (varies by LED)	10	10	10	10	10
Physical & Compliance
Dimensions (L × Ø)	600×30mm	900×30mm	1200×30mm	1500×30mm	2400×30mm
Beam Angle: (°)	180°	180°	180°	180°	180°
Housing Material	Aluminum + PC (Clear/Diffused)
IP Rating	IP65 (Waterproof)
Wiring Option	Direct-wire via PG7 waterproof gland (no ballast required)
Implementation standards	UL 8800, EN 62471 (Risk Group 1), RoHS 3 (EU 2015/863)

Available Models & Part Numbers

Model	Rank Code	Dimensions	Power	Input Voltage	Peak Wavelength		Spectral Ratio（%)		PPF	PPE Efficacy	Part Number
Device Model	Rank	(mm)	(W)	(V AC)	Min	Max	Red	Blue	(μmol/s)	(μmol/J)	P/N
PGT1020RB	PGT031	598×30	20	85–230 V	450	660	60%	40%	54	2.7	9405500000PG031
PGT1045RB	PGT032	898×30	36	85–230 V	450	660	60%	40%	97	2.7	9405500000PG032
PGT1020RB	PGT033	1198×30	48	85–230 V	450	660	60%	40%	130	2.7	9405500000PG033
PGT1080RB	PGT034	1498×30	60	85–230 V	450	660	60%	40%	162	2.7	9405500000PG034
Model	Rank Code	Dimensions	Power	Input Voltage	CCT(K)		Spectral Ratio（%)		PPF	PPE Efficacy	Part Number
Device Model	Rank	(mm)	(W)	(V AC)	MIN	MAX	WW	NW	(μmol/s)	(μmol/J)	P/N
PGT1025WW	PGT035	598×30	20	85–230 V	3000	6000	30%	70%	58	2.9	9405500000PG035
PGT1045WW	PGT036	898×30	36	85–230 V	3000	6000	30%	70%	104	2.9	9405500000PG036
PGT1060WW	PGT037	1198×30	48	85–230 V	3000	6000	30%	70%	139	2.9	9405500000PG037
PGT1080WW	PGT038	1498×30	60	85–230 V	3000	6000	30%	70%	174	2.9	9405500000PG038

Note: WW = Warm White; NW = Neutral ，White.PPFD: μmol/m²/s @ 100 cm from surface.

Spectral Options

Full-Sunlight Spectrum: Broadband white light (380–730 nm) combining 6000K (cool white) and 3000K (warm white) LEDs, closely mimicking natural daylight with enhanced red and far-red continuity. CRI >90, suitable for full-cycle plant growth.
Targeted Red-Blue (RB) Blend: Optimized ratio of 60% deep red (660 nm) + 40% blue (450 nm) for vegetative vigor and compact morphology; ideal for seedling, propagation, or energy-efficient supplemental lighting.
Advanced Full-Spectrum + FR: Full-sunlight base with added far-red (730 nm) for photomorphogenic control (shade avoidance, flowering acceleration) – available on select models.
All above are standard configurations. Custom spectral recipes (e.g., 70/30 RB, UV inclusion, tunable white, or multi-channel control) are available upon request for commercial or research applications.

Features

Integrated Design: One-piece construction for plug-and-play installation—no external drivers or brackets needed.
Dual Spectrum Options: Choose between targeted Red/Blue (660nm/450nm) for flowering or Full-Spectrum White (3000K + 6000K) for full-cycle growth.
High Light Transmittance: Transparent PC cover (94–96% transmittance) or diffused PC cover (85–92%) for uniform canopy coverage.
Flame-Retardant: PC housing meets UL94 V0/V2 safety standards.
Flexible Mounting: Compatible with standard T10/T12 fluorescent fixtures—supports surface, suspended, or rail mounting.
Global Voltage: Auto-ranging 85–230V AC, 50/60Hz—ready for worldwide use.
Compact Sizes: Available in 60cm, 90cm, 120cm, and 150cm lengths to fit any layout.

Benefits

Optimized Plant Growth: Scientifically balanced spectrum enhances chlorophyll absorption and photomorphogenesis.
Energy Efficient: Delivers up to 2.9 µmol/J photon efficacy—30% more efficient than traditional T5/T8 fluorescents.
Long Service Life: Rated for >50,000 hours (L90 > 36,000h), reducing replacement frequency and labor costs.
Passive Cooling: Aluminum PCB + thermally conductive housing ensures stable output in enclosed environments.

Applications

Indoor Gardening: Ideal for herbs, leafy greens, succulents, and houseplants under shelves or cabinets.
Greenhouses & Nurseries: Supplemental lighting during low-light seasons to maintain consistent crop cycles.
Research & Education: Stable, repeatable spectrum for plant physiology experiments in labs and classrooms.
Retrofit Projects: Direct replacement for existing T10/T12 fluorescent tubes—no rewiring required.
