What is the typical lifespan of this product?

The product is designed for long-term industrial use, with a typical lifespan of over 50,000 hours.

Do you support OEM or custom specifications?

Yes, we support OEM, ODM, and custom technical specifications based on project requirements.

What certifications are available?

Certifications vary by model and may include CE, RoHS, LM-80, and ISO-compliant manufacturing.

L1 linear LED grow lights

Technical Specifications

L1 Linear LED Grow Light

Dimensions: 900×x40x50 mm (3FT), 1200×x40x50 mm (4FT), 1500×x40x50 mm (5FT), 2400×x40x50 mm (6FT)
Light Source: High-efficiency SMD LEDs (Philips / OSRAM / Samsung / Hongli)
Housing: Extruded pure aluminum plate with passive cooling fins + optical-grade PC lens
Color Temperature: 6000K (cool white) / 3000K (warm white)
Spectral Range: 370–730 nm full spectrum
Spectral Options:
Full-spectrum white blend (6000K + 3000K) for full-cycle growth.
Optional targeted RB blend (660nm red + 450nm blue) with adjustable ratio per crop requirements.
UV (385nm) and far-red (730nm) available on custom models.
Power Options: 60W (3FT), 100W (4FT), 120W (5FT), 150W (6FT) – AC derated input power (model dependent)
Input Voltage: AC 85–265V, 50/60Hz (universal auto-ranging)
Power Factor: ≥0.95 (typical)
Photon Efficacy (PPE): 2.7 μmol/J (@25°C, system-level AC derated)
PPF Output: 162 µmol/s (60W), 270 µmol/s (100W), 324 µmol/s (120W), 405 µmol/s (150W)
Beam Angle: 120° (FWHM) standard
Operating Ambient Temperature: −20°C to +50°C
Protection Rating: IP65 (dust-tight & protected against water jets)
Lifespan: >50,000 hours (L90/B50 at 25°C; driver L90 >36,000h)
LED Chip Brands: Philips, OSRAM, Samsung, Hongli
Driver Brands: Approved constant-current drivers (Mean Well / Moso); optional 0–10V or PWM dimming
Installation: Surface-mounted via PG7 cable gland (hardware included); suitable for vertical farming and multi-layer racks
Certifications: UL 8800, EN 62471, RoHS, CE
Note: 2FT (600mm) model not available in current lineup. All units require direct line-voltage wiring (no ballast). Custom spectral recipes and lengths available for OEM.

Description

L1 linear LED grow lights

High-Efficiency Linear LED Grow Lights for Medium to Large-Scale Agriculture

Overview

The L1 series elongated plant grow lights feature a high-power integrated structure, specifically designed for medium to large-scale agricultural facilities. The integrated molding process eliminates complex installation steps, allowing for rapid deployment in high-density planting environments such as plant factories, greenhouses, and vertical farms.

Through precise red-blue spectrum matching or a combination of high color rendering white light (3000K/6000K), photosynthetic efficiency is effectively improved, with a maximum PPF output of 435 μmol/s and a stable PPF/W energy efficiency of 2.9 μmol/J. Balancing high output with low energy consumption, it is an ideal choice for large-scale smart agricultural lighting.

Product Electrical Index

Electrical & Photometric Specifications
Metric / Model	2FT	3FT	4FT	5FT	6FT
Input Voltage & Frequency	AC 85–230 V, 50/60 Hz
Rated Power (Typical W)	40	60	100	120	150
Power Factor (PF)	≥ 0.95	≥ 0.95	≥ 0.95	≥ 0.95	≥ 0.95
Dimming	Optional 0-10V, PWM
Driver Lifetime	~ 50 000h (L90>36 000h at 25°C)
Photometric Performance
WAVELENGTH [1] (nm)	370-730 nm	370-730 nm	370-730 nm	370-730 nm	370-730 nm
Photosynthetic Photon Flux (PPF) (µmol/s)	108	162	270	324	405
System Efficacy (PPE) (μmol/J)	2.7	2.7	2.7	2.7	2.7
LED-Only Efficacy (µmol/J)	3.02	3.02	3.02	3.02	3.02
Spectral Half-width (nm) (varies by LED)	10	10	10	10	10
Physical & Compliance
Dimensions (L × W × H)	600x40x50mm	900x40x50mm	1200x40x50mmm	1500x40x50mm	2400x40x50mm
Beam Angle: (°)	180°	180°	180°	180°	180°
Housing Material	Aluminum + PC (Clear/Diffused)
IP Rating	IP65 (Waterproof)
Wiring Option	Direct-wire via PG7 waterproof gland (no ballast required)
Implementation standards	UL 8800, EN 62471 (Risk Group 1), RoHS 3 (EU 2015/863)

Available Models & Part Numbers

Red/Blue Spectrum Table
Model	Rank Code	Dimensions	Power	Input Voltage	Peak Wavelength		Spectral Ratio（%)		PPF	PPE Efficacy	Part Number
Device Model	Rank	(mm)	(W)	(V AC)	Min	Max	Red	Blue	(μmol/s)	(μmol/J)	P/N
LPGT3060RB	LPG051	900x40x50	60	85–230 V	450	660	60%	40%	162	2.7	9405500000PG051
LPGT30100RB	LPG052	1200x40x50	100	85–230 V	450	660	60%	40%	270	2.7	9405500000PG052
LPGT30120RB	LPG053	1500x40x50	120	85–230 V	450	660	60%	40%	324	2.7	9405500000PG053
LPGT30150RB	LPG054	2400x40x50	150	85–230 V	450	660	60%	40%	405	2.7	9405500000PG054
Full Spectrum White Table
Model	Rank Code	Dimensions	Power	Input Voltage	CCT(K)		Spectral Ratio（%)		PPF	PPE Efficacy	Part Number
Device Model	Rank	(mm)	(W)	(V AC)	MIN	MAX	WW	NW	(μmol/s)	(μmol/J)	P/N
LPGT3060WWR	LPG055	900x40x50	60	85–230 V	3000	6000	30%	70%	174	2.9	9405500000PG055
LPGT30100WWR	LPG056	1200x40x50	100	85–230 V	3000	6000	30%	70%	290	2.9	9405500000PG056
LPGT30120WWR	LPG057	1500x40x50	120	85–230 V	3000	6000	30%	70%	348	2.9	9405500000PG057
LPGT30150WWR	LPG058	2400x40x50	150	85–230 V	3000	6000	30%	70%	435	2.9	9405500000PG058

Note: WW = Warm White; NW = Neutral ，White.PPFD: μmol/m²/s @ 100 cm from surface.

Spectral Options

Full-Sunlight Spectrum: Broadband white light (380–730 nm) combining 6000K (cool white) and 3000K (warm white) LEDs, closely mimicking natural daylight with enhanced red and far-red continuity. CRI >90, suitable for full-cycle plant growth.
Targeted Red-Blue (RB) Blend: Optimized ratio of 60% deep red (660 nm) + 40% blue (450 nm) for vegetative vigor and compact morphology; ideal for seedling, propagation, or energy-efficient supplemental lighting.
Advanced Full-Spectrum + FR: Full-sunlight base with added far-red (730 nm) for photomorphogenic control (shade avoidance, flowering acceleration) – available on select models.
All above are standard configurations. Custom spectral recipes (e.g., 70/30 RB, UV inclusion, tunable white, or multi-channel control) are available upon request for commercial or research applications.

Features

Material: Made of high-quality aluminum alloy or plastic, offering excellent heat dissipation.

Spectrum: Provides full-spectrum or specific spectrum (red, blue light) to meet the needs of different crop growth stages.

Light Transmittance: Transparent PC cover has a light transmittance of 94%-96%, while light-diffusing PC cover has a light transmittance of 85%-92%.

Flame Retardant Rating: The PC cover meets V2 or V0 flame retardant standards, ensuring safe use.

Installation Method: Supports hanging, fixed, or surface mounting, adaptable to various application scenarios.

Dimensions: Available in multiple lengths including 60cm, 90cm, 120cm, 150cm, and 240cm.

Input Voltage: Compatible with 110V and 220V AC power supplies, suitable for global market applications.

Benefits

Suitable Light Conditions: Provides optimal light spectrum and intensity to promote healthy plant growth.

High Efficiency and Energy Saving: With a luminous efficacy of up to 100 LM/W and a PPF/W value of 2.7-2.9 μmol/J, energy consumption is significantly reduced.

Long Lifespan: Designed for a lifespan exceeding 50,000 hours, reducing maintenance costs.

Excellent Heat Dissipation: Utilizes high-quality heat dissipation materials to ensure stable operation over extended periods.
