7070 LEDs

Name: 7070 LEDs
Brand: QUEENDOM

Technical Specifications

7070 High-Power LEDs

Package Size: 7.0 mm × 7.0 mm × 3.0 mm (with thermal pad)
Colors Available:
• Monochrome: Red (620–630 nm), Yellow (585–595 nm), Green (520–530 nm), Blue (450–460 nm), Purple (400–410 nm)
• White (phosphor-converted): 3000K, 4000K, 5000K, 6500K
Forward Voltage (V_F):
• Red / Yellow: 2.0 V – 2.4 V @ 350 mA
• Green / Blue / White / Purple: 2.8 V – 3.6 V @ 350 mA
• Multi-die configuration (series): 6 V, 9 V, or 12 V @ 350–1600 mA
Operating Current:
• Standard: 350 mA (continuous)
• High-power variants: up to 1600 mA (continuous, with thermal management)
• Pulsed operation: up to 2000 mA (10% duty cycle, 100 Hz)
Typical Power Consumption:
• Single-die white @ 1600 mA: ~5.1 W
• 4-die 12V @ 1600 mA: ~19.2 W (requires MCPCB and active cooling)
Luminous Efficacy (White): 120 – 180 lm/W (depending on CCT and bin)
Radiant Flux (Monochrome): Wavelength-dependent (e.g., 630 nm Red: 300–450 mW @ 1600 mA)
Viewing Angle: 120° (Lambertian emission)
Thermal Resistance (R_θJA): 8–12 °C/W (on recommended MCPCB)
Operating Temperature (Ambient): −40°C to +85°C
Maximum Junction Temperature (T_j): 150°C
Lifetime (L70/B50): ≥50,000 hours @ T_j ≤ 85°C
Compliance: RoHS, REACH, CE, IEC/EN 62471 (Photobiological Safety – Risk Group 1)

Description

7070 LEDs | High Power LED

Overview

Queendom 7070 LED is a multi-chip high-power LED in a high-power ceramic package; provides high brightness in an ultra-rugged package, composed of multiple chips, available for monochromatic light, RGB, RGBW, or white light; quad-core parallel design available Designed for cost-effective single light and directional luminaires, this product conducts heat 10 times faster than analog lumens.

7070 high-power LEDs deliver up to 20W output in a robust 7.0×7.0mm ceramic package, featuring high luminous efficacy (180 lm/W), excellent thermal management, and CRI options up to 90+. These chips are engineered for demanding applications including industrial floodlights, UV curing systems, horticultural grow lights, and high-bay fixtures.

Available Models & Part Numbers

7070 COLOR LEDs & Part Number

Table 1. Optical and Electrical Characteristics of Queendom LEDs at 700 mA and 1400 mA (Tj = 25 °C)

Model	Rank Code	Color Type	Wavelength (nm)		Luminous Flux (lm)		Forward Voltage VF (V)		Viewing Angle	Test Current	Part Number
Device Model	Rank	Typical λ (nm)	Min	Max	Min	Max	Min	Max	(2θ½, °)	(mA)	P/N
HP7070B52WF	HP0325	460	460	470	150	180	2.6	3.2	50	700	8541401000HP0325
HP7070B62WF	HP0326	470	470	480	150	180	2.6	3.2	50	700	8541401000HP0326
HP7070G02WF	HP0327	500	500	510	330	360	2.6	3.2	110	700	8541401000HP0327
HP7070G12WF	HP0328	510	510	520	360	390	2.6	3.2	120	700	8541401000HP0328
HP7070G22WF	HP0329	520	520	530	390	420	2.6	3.2	130	700	8541401000HP0329
HP7070G32WF	HP0330	530	530	540	360	390	2.6	3.2	125	700	8541401000HP0330
HP7070Y22WF	HP0331	585	585	595	150	200	1.8	2.4	55	700	8541401000HP0331
HP7070AO2WF	HP0332	605	600	610	150	200	1.8	2.4	60	700	8541401000HP0332
HP7070R22WF	HP0333	620	610	630	160	200	1.8	2.4	65	700	8541401000HP0333
HP7070R32WF	HP0334	630	620	640	160	200	1.8	2.4	60	700	8541401000HP0334
HP7070R42WF	HP0335	640	640	660	95	140	1.8	2.4	60	700	8541401000HP0335
HP7070R62WF	HP0336	660	660	680	24	30	1.8	2.4	30	700	8541401000HP0336
HP7070B52WG	HP0337	460	460	470	240	280	2.6	3.2	50	1400	8541401000HP0337
HP7070B62WG	HP0338	470	470	480	240	280	2.6	3.2	50	1400	8541401000HP0338
HP7070G02WG	HP0339	500	500	510	480	560	2.6	3.2	110	1400	8541401000HP0339
HP7070G12WG	HP0340	510	510	520	480	560	2.6	3.2	120	1400	8541401000HP0340
HP7070G22WG	HP0341	520	520	530	560	640	2.6	3.2	130	1400	8541401000HP0341
HP7070G32WG	HP0342	530	530	540	560	640	2.6	3.2	125	1400	8541401000HP0342
HP7070Y22WG	HP0343	585	585	595	280	320	1.8	2.4	55	1400	8541401000HP0343
HP7070AO2WG	HP0344	605	600	610	280	320	1.8	2.4	60	1400	8541401000HP0344
HP7070R22WG	HP0345	620	610	630	320	400	1.8	2.4	65	1400	8541401000HP0345
HP7070R32WG	HP0346	630	620	640	320	400	1.8	2.4	60	1400	8541401000HP0346
HP7070R42WG	HP0347	640	640	660	160	200	1.8	2.4	60	1400	8541401000HP0347

7070 WHITE LEDs & Part Number

Table 2. Optical and Electrical Characteristics of Queendom LEDs at 700 mA and 1400 mA (Tj = 25 °C)

Model	Rank Code	Color Type	CRI	Luminous Flux (lm)		Forward Voltage VF (V)		Efficacy	Viewing Angle	Test Current	Part Number
Device Model	Rank	CCT/K	(Ra)	MIN	MAX	MIN	MAX	(lm/W)	(2θ½, °)	(mA)	P/N
HP7070WY2WF	HP0301	2700K	80	190	240	2.80	4.60	135	120	700	8541401000HP0301
HP7070WV2WF	HP0302	3000K	80	190	240	2.80	4.60	140	120	700	8541401000HP0302
HP7070WU2WF	HP0303	3500K	80	190	240	2.80	4.60	143	120	700	8541401000HP0303
HP7070WT2WF	HP0304	4000K	80	190	240	2.80	4.60	150	120	700	8541401000HP0304
HP7070WR2WF	HP0305	5000K	80	190	240	2.80	4.60	155	120	700	8541401000HP0305
HP7070WQ2WF	HP0306	5700K	80	190	240	2.80	4.60	160	120	700	8541401000HP0306
HP7070WP2WF	HP0307	6500K	80	190	240	2.80	4.60	165	120	700	8541401000HP0307
HP7070WD2WF	HP0308	7600K	80	190	240	2.80	4.60	130	120	700	8541401000HP0308
HP7070WY2WG	HP0309	2700K	80	210	430	4.80	6.90	135	120	1000	8541401000HP0309
HP7070WV2WG	HP0310	3000K	80	210	430	4.80	6.90	140	120	1000	8541401000HP0310
HP7070WU2WG	HP0311	3500K	80	210	430	4.80	6.90	143	120	1000	8541401000HP0311
HP7070WT2WG	HP0312	4000K	80	210	430	4.80	6.90	150	120	1000	8541401000HP0312
HP7070WR2WG	HP0313	5000K	80	210	430	4.80	6.90	155	120	1000	8541401000HP0313
HP7070WQ2WG	HP0314	5700K	80	210	430	4.80	6.90	160	120	1000	8541401000HP0314
HP7070WP2WG	HP0315	6500K	80	210	430	4.80	6.90	165	120	1000	8541401000HP0315
HP7070WD2WG	HP0316	7600K	80	210	430	4.80	6.90	130	120	1000	8541401000HP0316
HP7070WY8WI	HP0317	2700K	80	360	640	9.00	12.00	135	120	1400	8541401000HP0317
HP7070WV8WI	HP0318	3000K	80	360	640	9.00	12.00	140	120	1400	8541401000HP0318
HP7070WU8WI	HP0319	3500K	80	360	640	9.00	12.00	143	120	1400	8541401000HP0319
HP7070WT8WI	HP0320	4000K	80	360	640	9.00	12.00	150	120	1400	8541401000HP0320
HP7070WR8WI	HP0321	5000K	80	360	640	9.00	12.00	155	120	1400	8541401000HP0321
HP7070WQ8WI	HP0322	5700K	80	360	640	9.00	12.00	160	120	1400	8541401000HP0322
HP7070WP8WI	HP0323	6500K	80	360	640	9.00	12.00	165	120	1400	8541401000HP0323
HP7070WD8WJ	HP0324	7600K	80	360	640	9.00	12.00	168	120	1400	8541401000HP0324

Features

White LED Only

Correlated Color Temperature (CCT): 3000K, 4000K, 5000K, 6500K, up to 9000K
Color Rendering Index (CRI): ≥70 (standard), ≥80 (high-CRI option), ≥90 (premium option)
Efficacy: 120 – 180 lm/W

Packaging and Materials

Packaging Form: SMD packaging with ceramic substrate
Main Chips: CREE, Osram, Epistar, Sanan; materials include gallium arsenide (GaAs), sapphire (Al₂O₃), etc.
Chip Range: 30×30 mil to 45×45 mil
Package Wires: High-purity 99.99% gold or copper wires for reliable electrical conductivity
Bracket Material: PCT, PPA, EMC (aluminum alloy or copper alloy); covered with an electrical insulation layer such as ceramic or high-temperature plastic
Packaging Glue: Silicone + resin glue
Display Index: Available in 70CRI, 80CRI, and 90CRI
Lighting Method: Single color, multi-color, bi-color, RGB, color
Colloidal Color: Water clear, yellow diffused
Voltage Configurations: Compatible with multiple voltage configurations: 3V, 6V, 24V

Benefits

High Brightness: Exceptional luminous efficacy of 120 – 180 lm/W
Low Power Consumption: Efficient energy use reduces operational costs
Long Life: Durable design ensures long-term reliability
Easy Installation: Small size and light weight facilitate convenient installation
Excellent Heat Dissipation: Low thermal resistance (Rth) materials enhance heat dissipation, improving efficiency and maintaining ANSI bin color consistency at 85°C
Good Color Uniformity: Colored light uses a 2.5nm binning structure; warm white light is binned at 200K/PIN, pure white at 500K/PIN, ensuring excellent color uniformity
Compatibility with Automated Equipment: Suitable for automatic placement equipment
Infrared and Vapor Phase Reflow Soldering Compatibility: Designed for compatibility with advanced soldering processes

Applications

Indoor and Outdoor Lighting: Home lighting, commercial lighting, street lighting
Displays and Signage: Commonly used in displays, billboards, and other signage applications
Automotive Applications: Instrument panels, brake lights, turn signals
Biomedical Optics: Instrumentation and equipment testing
Status Indicators: Consumer electronics and industrial electronics
Security Systems: Infrared monitoring, night vision

In summary, the 7070 High-Power LED family provides high-performance lighting solutions with exceptional brightness, efficiency, and durability. With their advanced features and benefits, these LEDs are ideal for a variety of applications, making them a reliable choice for your lighting projects.
